A III generation Dental Microscope "CALIPSO"
Meet the Scaner «CALIPSO» 4th Generation Microscope
35 years of engineering evolution. Hands-on experience of practicing doctors. Technology refined to perfection.
Key Advantages:
1. Optics Without Compromise
- High-quality optical glass from SCHOTT (Germany).
- Multi-layer anti-reflective coating.
- Vario objective 200–450 mm.
- CRI = 94% — natural color reproduction and maximum detail.
2. One Finger Control
Complete control with a single movement. No distractions. No unnecessary actions.
3. Smart Light
Intelligent light adaptation. Perfect balance at any magnification.
4. Fluorescent Light
An enhanced level of visual diagnostics for superior precision.
5. MORA Interface
Ideal ergonomics, no neck or back fatigue. Full concentration on the patient.
6. Color OLED Screen
Modern and user-friendly interface for real-time monitoring.
7. Procedure Documentation
Support for adapters compatible with GoPro, Sony Alpha, and smartphones.
8. Excellence in Engineering
- Balanced kinematics for smooth movement.
- Hidden cable architecture for safety and aesthetics.
- Sealed optical system with passive LED cooling.
- Integration of USB and Type-C ports.
9. Premium coating by KABE-Farben
Superior resistance to disinfection agents and mechanical stress.
Scaner «CALIPSO»
Confidence in every movement. Clarity in every detail.
+ 5 years warranty
Contacts:
📞 +38 (096) 886-08-86
📞 +38 (067) 355-32-79
📞 +38 (067) 356-54-63
✉️ sale@scaner.com.ua
CALIPSO — your next-generation microscope!
The products of SCANER Company comply with the requirements of the European Directive MDD 93/42/EEC, as well as the Technical Regulation on Medical Devices in Ukraine.
SCANER Company is certified in accordance with the requirements of the international standard ISO 13485:2016.
our manager will contact you shortly
Customer photos
other hardware companies
|
Diagnostic Microscope MD-500 «CALIPSO» ISO 13485:2016 |
|||||||
|
|
Sales Department
+38 (096) 886 0 886 +38 (073) 021 16 76 sale@scaner.ua www.scaner.ua |
Simple |
Standard |
Superior |
|||
|
Code |
Stands |
||||||
|
61600 |
Mobile floor base + stand |
✔ |
|||||
|
64600 |
Ceiling mount (ceiling height up to 3.7 m) |
|
|||||
|
62700 |
Wall mount |
|
|||||
|
Binocular Heads |
|||||||
|
50600 |
Binocular head 0° or 45° |
✔ |
|||||
|
60800 |
Binocular head ±90° with axial rotation mechanism |
|
✔ |
✔ |
|||
|
Objectives |
|||||||
|
64200 |
Objective f 200, 250, 300, 350, or 400 mm (with fine focus) |
✔ |
|||||
|
52800B02 |
Variobjective with protective glass and working distance 200 – 400 mm |
|
✔ |
✔ |
|||
|
Optical Splitters |
|||||||
|
63902А |
0° adapter with 20/80 optical splitter for 1 channel |
✔ |
|||||
|
52100В |
60° adapter with 20/80 optical splitter for 1 channel |
|
✔ |
✔ |
|||
|
Innovative Features |
|||||||
|
«Smart Light» – automatic lighting adjustment system when changing magnifications |
✔ |
✔ |
✔ |
||||
|
«Fluorescent Light» – fluorescent backlight mode + special filter system for eye protection and to enhance the contrast of the fluorescent image |
|
|
✔ |
||||
|
Photo and Video Adapters |
|||||||
|
62200 |
Adapter for Sony™ cameras |
|
|||||
|
64100 |
4D adapter for smartphones with the «SOVA» mobile app |
|
|||||
|
64900А |
Adapter with GoPro-12 camera and media module |
|
|||||
|
Additional Accessories |
|||||||
|
64000 |
Monitor mount stand (for microscope stand) |
|
|||||
|
65100 |
Tablet mounting and connection system |
|
|||||
|
|
Set of silicone caps |
|
|||||
|
|
«Vyshyvanka» or «Kalyna» pattern on the power supply unit |
|
|||||
|
|
Customer logo on the illuminator cover |
|
|||||
|
Optical Head Specifications and Features – Optical magnification at 200 mm working distance – 4Х, 6Х, 9Х, 15Х 24Х – Optical magnification at 400 mm working distance – 2.2Х, 3.7Х, 5.5Х, 9Х, 15Х – LED illuminator with passive cooling – 115,000 Lux (at 200 mm working distance), 6500K, CRI = 94 – Manual lighting adjustment handle and switching to «Smart Light» mode – Handle for activating «Fluorescent Light» mode and eye protection filter handle – Lever for activating orange and blue light filters Additional Features – Automatic light shut-off when the optical head is raised to the non-working zone – 2 USB ports on the optical head bracket for powering a video camera, smartphone, or tablet – On-screen display of current magnification, «Smart Light», «Fluorescent Light» modes, and LED temperature – Protection system for the power supply unit and parallelogram against damage during assembly |
|||||||
Products of «SCANER» Company comply with the requirements of European Directive MDD 93/42/EEC,
as well as the technical regulations for medical devices in Ukraine
«SCANER» Company is certified according to the requirements of international standard ISO 13485:2016
5-year warranty
